Allied LSP Oxygen Pressure Regulator 0-25 lpm CGA 870 L270-220 2 Check Valves

Allied LSP Oxygen Pressure Regulator 0-25 lpm CGA 870 L270-220 with 2 check valves

The Life Support Products series of all-brass body oxygen pressure regulators provides enhanced safety features and a greater number of flow selections for the EMS professional. The uni-body construction is designed to strengthen the regulator, minimize potential leak paths, and prevent breakage of the yoke cylinder connection assembly. For additional safety, inlet filters provide gas filtration down to 20 microns. Standard LSP regulators have a 5 year warranty. LSP regulators offer 12 flow positions ... more flow selections than ever before. Equipped with up to two DISS check valves, LSP regulators provide regulated pressure and flow for the operation of two demand valves, or one demand valve and one aspirator, or any pneumatically-powered ventilator. A DISS or hose barb adjustable flow outlet permits attachment of a disposable mask, cannula, or bag mask device. All outlet configurations may be operated simultaneously.

• Uni-body construction designed to prevent yoke breakage and regulator leakage, and provide complete protection to the constant flow selector knob
• Nickel-plated brass body is fire resistant and able to withstand corrosive materials, the marine environment, and harsh weather conditions
• Sintered bronze high-pressure inlet filter for enhanced protection against contamination
• Compact break-resistant low profile contents gauge
• Large easy to read flow rate numbers
• Two body designs are available: yoke inlet for small cylinders, and nut and nipple inlet for large cylinders
• Hose barb outlet connection for oxygen supply to patient
• All LSP brass oxygen regulators are laser-engraved with the LSP logo, model number, date code and bar code to assist in preventing loss and tracking for routine maintenance.
• This specific model: 0-25 lpm, with gauge, 2 check valves, hose barb outlet
• Yoke Pin Indexed CGA 870 Regulator
• 5 year warranty
• Manufacturer: Allied Healthcare Products
• Manufacturer's Product ID: L270-220

Specifications

• Supply Pressure: 500 to 2200 psi
• Outlet Pressure: High flow outlets: 40 to 60 psi at 500 to 2200 psi inlet pressure
• Flow Capacity: High flow outlets: 125 lpm minimum single or combined flow with 500 psi inlet pressure
• Constant flow outlet selections: 0-15 lpm: 0, .5, 1, 1.5, 2, 3, 4, 5, 6, 8, 10, 15
• Constant flow outlet selections: 0-25 lpm: 0, .5, 1, 2, 4, 6, 8, 10, 12, 15, 20, 25
• Filter: 25 micron sintered bronze
• Safety Relief Pressure: 75-125 psi
• Operating Temperature: -30°F to 125°F
• Storage Temperature: -20°F to 120°F
• Materials: Body: nickel-plated brass; knob-anodized aluminum; outlets-nickel-plated brass; Internal Parts-brass, stainless steel, Viton, silicon, and Teflon
