Bovie Colposcope Colpo-Master I

Bovie Colposcope Colpo-Master I

The Colpo-Master I Colposcope is perfect for the GYN performing both exams and procedures. The swing-arm design allows easy access to the vaginal canal during procedure aiding procedure efficiency.

Colpo-Master I Colposcope features smooth, continuous zoom 4-27x magnification with 20x eyepieces and sharp focus for 3-D imaging. The units available with Binocular or the EMR compatible and camera-ready Trinocular heads with 298mm working distance. The field of view (FOV) ranges from 58.5mm at 4x to 8.5mm at 27x. All models are available with the choice of 3 or 5 leg sturdy mobile bases.

Designed for viewing comfort; each colposcope model has dual diopter adjustments to independently adjust the focus of both Left and Right eyepieces to eliminate eyestrain. Camera-ready Trinocular models allow the user to view through both eyepieces while using the camera.

Colpo-Master I Suspension Arm is rock-steady. To make head positioning easy it comes with locking casters and stainless steel handlebars, standard.

• Colposcope designed for gynecological exams and procedures
• Smooth, continuous zoom ranges from 4-27x magnification with 20x eyepieces and sharp focus for 3-D imaging
• These colposcopes are available with Binocular or the EMR compatible and camera-ready Trinocular heads with 298mm working distance
• The field of view (FOV) ranges from 58.5mm at 4x to 8.5mm at 27x
• Available with either 3 or 5 leg sturdy mobile bases
• Low center of gravity increases stability, while EZ-Roll locking casters provide smooth gliding movement between exam rooms
• Dual diopter adjustments to independently adjust the focus of both Left and Right eyepieces to eliminate eyestrain
• Suspension Arm is very steady and comes with locking casters and stainless steel handlebars
• The Colpo-Master I Colposcope comes complete with dust cover, power cord, manual, and tool kit
• Seven Year Limited Warranty (1 year on electrical system (excludes bulbs and fuses))
• Manufacturer: Bovie Medical
• Available Models and Packages:
  • CS-103LED: Binocular Head, Zoom Suspension-Arm, 3-leg base
  • CS-105LED: Binocular Head, Zoom Suspension-Arm, 5-leg base
  • CS-103T-LED: Trinocular Head, Camera-Ready, Zoom Swing-Arm, 3-leg base
  • CS-105T-LED: Trinocular Head, Camera-Ready, Zoom Swing-Arm, 5-leg base
  • CS-103T-DV: Trinocular Head, Digital Video Package, Zoom Swing-Arm, 3-leg base
  • CS-103T-SV: Trinocular Head, S-Video Package, Zoom Swing-Arm, 3-leg base
  • CS-103T-SVM: Trinocular Head, S-Video Package, Monitor, Zoom Swing-Arm, 3-leg base
  • CS-103T-SDV: Trinocular Head, S-Video Package, Monitor, Frame Grabber Package, Zoom Swing-Arm, 3-leg base

Digital Video Package: Digital video camera, 5.6 MP, CCD, C-Mount, USB cable, Windows XP/7 software

S-video package: S-video color camera, 1/3" CCD, 480 TVL, S-video cable, power supply, C-Mount

Frame Grabber Package: For S-video to Digital, USB plug, image capture software

Contact us for additional video and monitor accessories.

Important Note: This product is oversized/heavy weight and is not covered under our Free Shipping option. This item is delivered by truck via dock delivery and an optional liftgate delivery with an additional cost. Contact us if you have any questions.
